Description
IF YOU ARE INTERESTED IN THIS PRODUCT, PLEASE SEND US AN ENQUIRY VIA EMAIL AND WE WILL GET BACK TO YOU. THIS ITEM IS ON SPECIAL ORDER BASIS!!
THIS IS WHEN SQUARE MATTERS!!!
The heavy-duty motor structure includes a large-diameter spider for less flex, longer life and superior accuracy. High-temp voice coil wire winding completes a powerful Comp motor that makes the most of every watt you give it.
Features:
- Dual Two-Ohm Voice Coils
- Injection-Molded Polypropylene Cone
- Patented Corner Ribs Minimize Distortion
- SoloKon™ 360-Degree Back Bracing
- Ribbed Santoprene Surround With Blue Surround Stitching
- UniPlate™ Back Plate And Pole Piece, Plus Perimeter Venting For Excellent Thermal Management
- Thick Tinsel Leads
- Large Ceramic Magnet
- Cast Aluminum Basket
- Satin-Nickel Plated, Spring-Loaded Speaker Terminals
Want setup help? Go to KICKERU for a free woofer & amplifier configuration app!
*The Solo-Baric L7S 15-Inch Subwoofer works best with a sealed or ported enclosure and 1,000 watts of recommended power. See below for more details.
Specifications
| Thiele/Small Parameters |
| 44L7S152 T/S Parameters |
| Product Dimension Sheet |
| 44L7S152 Dimensions |
| Size (IN.,CM) |
| 15, 38.1 |
| Impedance (OHMS) |
| 2 DVC |
| Recommended Amplifier Power (watts RMS) |
| 1000 |
| Peak Power (watts, per ANSI/CTA-2031-A) |
| 2000 |
| Sensitivity (dB 1w/1m) |
| 89.4 |
| Frequency Response (Hz) |
| 18-100 |
| Mounting Depth (IN.,CM) |
| 8-11/16, 22.1 |
| Mounting Cutout, Square (IN.,CM) |
| 13-3/4, 34.9 |
| Min Rec Sealed Box Volume (CU. FT., Liters) |
| 2.0, 56.64 |
| Max Rec Sealed Box Volume (CU. FT., Liters) |
| 6.0, 169.9 |
| Min Rec Vented Box Volume (CU. Ft., Liters)** |
| 3.0, 85.0 |
| Max Rec Vented Box Volume (CU. Ft., Liters)** |
| 6.0, 169.9 |
